| Category | Specifications |
| Function | Towing, fuel/fresh water/spare transfer, anchor and pipeline handling, buoy handling, spare parts lift, etc |
| Model | JLWB-700/700HP Multi Cat Work Boat (Non-dismountable type) |
Principal Dimensions
| Description | Specifications |
| Beam Max | 5.5 m |
| Hull Depth | 2.0 m |
| Empty Draft/Full Load Draft | 1.0 m / 1.3 m |
| Speed | 8-10 Knots |
| Pollard Pull | 5 t |
| Total Power | 700 hp |
Engine
| Brand | CUMMINS |
| Model | NTA855-M |
| Power | 261 kW @ 1800 rpm / 350 HP |
| Quantity | 2 sets |
Gear Box
| Brand | Woihao |
| Quantity | 1 set |
Hydraulic Winch
| Model | XH60 |
| Capacity | 60 KN / 1 set |
| Brand | XINHONG |
Hydraulic Knuckle Crane Boom
| Brand | XUZHOU HAOYI |
| Capacity | 10 m @ 1.4 tons / 2 m @ 10 tons |
Propulsion System
| Steering Gear | 2 sets |
| Stream-line Rudder | 2 pieces with rudder angle indicator in cabin |
| Propeller | 800 mm x 2 pieces |
Tanks Capacity
| Fuel Tank | 33,000 Liters (Customized) |
| Fresh Water Tank | 8,000 Liters (Customized) |
| Sewage Tank | 5,500 Liters (Customized) |
Life-Saving & Fire Fighting Apparatus
| Life Jackets | 4 pieces |
| Life Buoy | 4 pieces |
| Fire Extinguisher | 2 pieces |
| Life Raft | 1 set for six crew |
Electric System
| Network | 24V/220V/380V |
| Diesel Generator | 70 KW / 1 set |
| Brand | CUMMINS |
Communication
| Navigation Light | Installed |
| Search Light | Installed |
| Horn | 1 pieces |
| VHF | 4 pieces |
Steel Plate Specifications
| Side Plate | 8 mm |
| Fore & Rear Plate | 8 mm |
| Main Deck | 8 mm |
| Fore Deck | 8 mm |
| Bottom | 10 mm |
| Anchor | 1 pieces |
Anti-Corrosion
| Marine Painting | 4 layers (Jotun Marine Paint) |
| Zinc Anode | 12 pieces |
| Color | Per customer request |
Hydraulic Pump
| Brand | Denison |
| Quantity | 1 set (for rudder system and winch) |
Deck
| Plank | Complete deck |
| Handrail | Around deck |
| Rubber Fender | Around deck |
Anchor
| Type | Delta Type, 80 kg / 1 piece |
